Choice RSTAT1

Product Description

This Choice basic mechanical room thermostat is an economical and simple to use room thermostat. Simply turn the mechanical control dial to your desired temperature to control your room temperature. This unit also produces an audible “click” when you turn the dial past the current temperature so you know when the system is being turned ON or OFF.

This mechanical 2 wire thermostat is very easy to install and having volt free contacts is suitable for systems with either a combination or normal boiler. If you have a three wire installation, simply cut back and make safe the neutral and this two wire thermostat will give you years of faithful service.

Dual diaphragm temperature sensing element
Suitable for surface or patress box mounting
10 to 30°C Set point range
10 Amp current rating
ErP Class I
2 Wire Installation
Three terminal heating/cooling changeover

Power Supply: 230V Ac, 50-60Hz
Temperature setting Range: 10°C to 30°C
Current Rating: 10(3) Amp
Terminal Differential: Approx 4°C
Operating Temperature Range: 0°C to 40°C
Dimensions: L83 x H83 x D37
Complies with: EN60730-1, En60730-2.9, EMC Directive 2004/108/EC, LVD Directive 2006/95/EC

For volt free applications connect to terminals as follows:
1 - Input
3 - Heating Output
4 - Cooling Output (optional)

Sangamo Choice RSTAT1 Wiring Diagram
